AXIAL LEAD ZENER DIODES FEATURES
- Planar Die construction
- 500mW Power Dissipation
- Ideally Suited for Automated Assembly Processes
- Lead free in compliance with EU RoHS 2011/65/EU directivesMECHANICAL DATA
- Case: Molded glass DO-35
- Terminals: Solderable per MIL-STD-750, Method 2026
- Packing informationB/P - 2K per Bulk box
T/R - 10K per 15" plastic Reel
T/B - 5K per horiz. tape & Ammo boxHZ2B1~HZ36
Type
Suffix VZ@Izt
1
2
3
Test condition
Dynamic resistance
Reverse current
Min
Max
Min
Max
Min
Max
IZT
Zzt@IZT
IR MAX
VR
V
V
V
V
V
V
mA
Ω
μA
V
HZ2
B
1.9
2.1
2.0
2.2
2.1
2.3
5
100
5
0.5
C
2.2
2.4
2.3
2.5
2.4
2.6
HZ3
A
2.5
2.7
2.6
2.8
2.7
2.9
5
100
5
0.5
B
2.8
3.0
2.9
3.1
3.0
3.2
C
3.1
3.3
3.2
3.4
3.3
3.5
HZ4
A
3.4
3.6
3.5
3.7
3.6
3.8
5
100
5
1.0
B
3.7
3.9
3.8
4.0
3.9
4.1
C
4.0
4.2
4.1
4.3
4.2
4.4
HZ5
A
4.3
4.5
4.4
4.6
4.5
4.7
5
100
5
1.5
B
4.6
4.8
4.7
4.9
4.8
5.2
C
4.9
5.1
5.0
5.2
5.1
5.3
HZ6
A
5.2
5.5
5.3
5.6
5.4
5.7
5
40
5
2.0
B
5.5
5.8
5.6
5.9
5.7
6.0
C
5.8
6.1
6.0
6.3
6.1
6.4
HZ7
A
6.3
6.6
6.4
6.7
6.6
6.9
5
15
1
3.5
B
6.7
7.0
6.9
7.2
7.0
7.3
C
7.2
7.5
7.3
7.7
7.5
7.9
HZ9
A
7.7
8.1
7.9
8.3
8.1
8.5
5
20
1
5.0
B
8.3
8.7
8.5
8.9
8.7
9.1
C
8.9
9.3
9.1
9.5
9.3
9.7
HZ11
A
9.5
9.9
9.7
10.1
9.9
10.3
5
25
1
7.5
B
10.2
10.6
10.4
10.8
10.7
11.1
C
10.9
11.3
11.1
11.6
11.4
11.9
HZ12
A
11.6
12.1
11.9
12.4
12.2
12.7
5
35
1
9.5
B
12.4
12.9
12.6
13.1
12.9
13.4
C
13.2
13.7
13.5
14.0
13.8
14.3
HZ15
14.1
14.7
14.5
15.1
14.9
15.5
5
40
1
11
HZ16
15.3
15.9
15.7
16.5
16.3
17.1
5
45
1
12
HZ18
16.9
17.7
17.5
18.3
18.1
19.0
5
55
1
13
HZ20
18.8
19.7
19.5
20.4
20.2
21.1
2
60
1
15
HZ22
20.9
21.9
21.6
22.6
22.3
23.3
2
65
1
17
HZ24
22.0
24.0
23.6
24.7
24.3
25.5
2
70
1
19
HZ27
25.2
26.6
26.2
27.6
27.2
28.6
2
80
1
21
HZ30
28.2
29.6
29.2
30.6
30.2
31.6
2
100
1
23
HZ33
31.2
32.6
32.2
33.6
33.2
34.6
2
120
1
25
HZ36
34.2
35.7
35.3
36.8
36.4
38.0
2
140
1
27
